Micromax 200C
Specification
Model
|
MMX 200C CDMA 1x USB Modem
|
Network
|
CDMA 1X
|
Frequency Band
|
CDMA 1X
|
Specifications
|
Description
|
Form factor
|
USB dongle
|
Host Interface
|
USB
|
Antennas
|
Embedded/Internal
|
RF Test point
|
Yes
|
Main Features
|
|
Specifications
|
Description
|
Auto-Install Software
|
Yes
|
Operating System
|
Win2000/ XP/VISTA
|
Memory Card Slot
|
YES, can support upto 2GB of Memory Card
|
Specifications
|
Description
|
Chipset
|
Qualcomm Chipset, QSC6020
|
Power
|
USB Port (DC 5.0V)
|
Data Rate
|
Uplink/Downlink upto 153.6 kbps
|
RF Technology
|
Zero Intermedia Frequency
|
Memory
|
Flash Rom: 128 bit, Ram: 32 bit
|
Reference Sensitivity Level
|
below ~104dBm
|
Frequency Range
|
869.04~893.97 MHz
|
Interface Rejection
|
Single tone (-30dBm @900KHz): below -101dBm, Two
tone(-43dBm@1700KHz): below -101dBm
|
Spurious Wave Supression
|
below -80dBc
|
Input Dynamic Range
|
-25dBm ` -104dBm
|
Frequency Range
|
824.04 ~ 848.97 MHz
|
Nominal Power
|
0.32 W
|
Minimum controlled Output Power
|
below -50dBm
|
Max Power Spurious
|
900 KHz: below -42dBc/30KHz, 1700 KHz: below
-54dBc/30KHz
|
Micromax 351G
Specification
Model
|
HSPA USB MODEM
|
HSUPA
|
3GPP Release6, up to 5.76M bps UL,category 6
|
HSDPA
|
3GPP Release6, up to 7.2M bps DL,category 7/8
|
UMTS
|
3GPP Release4, up to 384 Kbps DL and UL
|
EDGE
|
3GPP Release4, Multislot class 12, up to 237 Kbps
|
GPRS
|
3GPP Release4, Multislot class 10, up to 85.6Kbps
|
GSM/GPRS/EDGE
|
850/900/1800/1900 MHz
|
UMTS
|
2100 MHz
|
Power Class
|
|
WCDMA
|
Power Class 3
|
GSM 850/900
|
Power Class 4
|
EDGE 850/900/1800/1900
|
Power Class E2
|
UMTS/GSM Antenna
|
Supported, Internal Antenna
|
USB Type
|
Standard USB Interface
|
USB Speed
|
USB 2.0 High Speed
|
Power Mode
|
Powered via the USB interface
|
SIM/USIM Card
|
Standard 6 PIN SIM card interface, compaliant
with 3GPP 31.101 and 31.102
|
AT Interface
|
3GPP TS27.005/3GPP TS27.007 supported
|
Form Factor
|
Rotating USB Dongle
|
Dimension (mm)
|
79.0mm(L) * 25.0mm(W) * 11.8mm(H)
|
Weight
|
< 30gms
|
Visual Indicator(LED)
|
RGB LED indicator for different state.
|
Languages Supported
|
English
|
Zero-CD installation
|
Supported
|
Operate System Supported
|
Windows 2000 SP4/ XP SP2/ VISTA, Windows 7
Mac OS X 10.4.9 or higher (only support INTEL platform), up to
10.6.0
|
Micro-SD Card Slot
|
Supported, Max up to 8GB
|
Certification
|
|
ROHS
|
Supported
|
Microsoft WHQL
|
Supported
|
Others
|
Could be supported upon request
|
Attention
|
For MAC OS: 1.Mac Book, Mac Book Pro, iMac, Mac
Pro or Mac mini (Intel CPU) 2.Mac OSX 10.4.9 or higher, up to
10.6.0\
|
Micromax 200G
Specification
Model
|
MMX 200G
|
Size
|
Whole: 85.5mm x 26mm x 12mm, PCBA: 78.05mm x
21.7mm x 7.45mm
|
Type
|
Bar
|
Hardware Spec.
|
|
Platform
|
MT6235B
|
Band
|
GSM/GPRS/EDGE Tri-Band(900/1800/1900 MHz)
|
Antenna
|
Built-In
|
Memory
|
NOR+PSRAM(64Mb+32Mb)
|
Interface
|
USB2.0(Full speed)
|
LED
|
1 blue LED
|
Software Spec.
|
|
OS
|
MT6235B
|
PC OS
|
GSM/GPRS/EDGE Tri-Band(900/1800/1900 MHz)
|
PC Driver
|
Built-In
|
Phonebook
|
NOR+PSRAM(64Mb+32Mb)
|
SMS
|
USB2.0(Full speed)
|
Voice Call
|
1 blue LED
|
Languages
|
English
|
General Features
|
|
Dimension
|
85.5mm x 26mm x 12mm
|
Band
|
Yes
|
Output power
|
|
Supply voltage range
|
4.2V ~ 5.2V (500mA is necessary)
|
Power consumption
|
< 2.5W
|
Storage temperature
|
-30�C ~ +80�C
|
Normal operation temperature
|
-10�C ~ +50�C
|
Restricted operation temperature
|
-10�C ~ -20�C and +50�C ~ +60�C
|
USB connector stick
|
USB2.0 (full speed)
|
SIM card
|
Only one
|
GMSK
|
|
Class 1
|
1W @ 1800/1900MHz
|
Class 4
|
2W @ 900MHz
|
8PSK
|
|
Class E2
|
0.5W @ EGSM900, 0.4W @ DCS1800/PCS1900
|
GPRS/EDGE multi-slot class
|
Class 10 (MT6235 can support GPRS class 12)
|
Coding scheme
|
CS1~4, MCS1~9
|
Mobile station
|
Class B
|
Data Spec.
|
|
GPRS
|
Max: 85.6Kbps
|
EDGE
|
DL&UL max: 236.8Kbps
|
Coding scheme
|
CS1~4, MCS1~9
|
AT cellular comm. and interface
|
GSM 07.07, 07.05 and New Wireless enhanced AT
commands
|
PBCCH
|
|
USSD
|
|
Operating System
|
Windows 2000/XP/Vista/7
|
Driver
|
Microsoft certified; Automatically install
|
Phonebook
|
SIM card; PC: 1000
|
SMS
|
SIM card; PC: Inbox-1000, Outbox-500 Draft-500
|
Group SMS
|
Support: 1000 (Customizable)
|
Languages
|
English
|
Micromax 300C
Specification
Model
|
MMX 300C EVDO Rev.A USB Modem
|
Network
|
CDMA 1X EVDO Rev A
|
Frequency Band
|
CDMA 1X EVDO Rev A
|
ID/MD
|
|
Specifications
|
Description
|
Form factor
|
USB dongle
|
Host Interface
|
USB
|
Size
|
72*30.8*12.5mm
|
Antennas
|
Embedded/Internal
|
RF Test point
|
Yes
|
Main Features
|
|
Specifications
|
Description
|
Auto-Install Software
|
Yes
|
Operating System
|
Win2000/ XP/VISTA
|
Memory Card Slot
|
YES, can support upto 4GB of Memory Card
|
Phone Book
|
|
Phone Book Capacity
|
1000 in PC
|
New contacts
|
Supported
|
Edit contacts
|
Supported
|
Delete contacts
|
Supported
|
Send SMS
|
Supported
|
Move between Modem, SIM card and PC
|
Supported
|
SMS
|
|
SMS Capability
|
1000 in PC
|
Group messages
|
Supported
|
New SMS
|
Supported
|
Send SMS
|
Supported
|
save SMS to drafts
|
Supported
|
Reply SMS
|
Supported
|
Forward SMS
|
Supported
|
Delete SMS
|
Supported
|
Import from SIM/Modem to PC
|
Supported
|
Micromax 310G
Specification
Model
|
MMX 310G HSDPA USB Modem
|
Technical Standard
|
|
HSDPA
|
3GPP R5, up to 3.6 Mbps DL and 384 Kbps UL,
category 5/6
|
UMTS
|
up to 384 Kbps DL and UL
|
EDGE
|
3GPP Release4, class 12, up to 237 Kbps DL and
118Kbps UL
|
GPRS
|
up to 85,6 Kbps DL and 42,8 Kbps UL
|
Frequency Band
|
|
GSM/GPRS/EDGE
|
850/900/1800/1900 MHz
|
UMTS
|
2100 MHz
|
External Interface
|
|
Antenna
|
Internal antenna
|
USB
|
Standard USB interface: supporting USB 2.0 Full
Speed
|
Power
|
Powered via the USB interface
|
SIM/USIM Card
|
standard 6 PIN SIM card interface, compliant with
3GPP 31.101 and 31.102
|
AT Interface
|
3GPP TS27.005/3GPP TS27.007supported
|
Main Features
|
|
Auto-Install Software
|
Supported
|
Dimension (mm)
|
64.7(D)*25.5(W)*10.6(H) (USB Head not included)
|
Weight
|
30 gm
|
One RGB LED
|
RGB LED indicates different state.
|
SIM/USIM Pin lock
|
Enable/Disable
|
Simultaneous Operation of SMS and Data service
|
Supported
|
Operating System
|
Win2000/ XP/VISTA, Limited support for MAC/Linux
Operating Systems
|
Phone Book
|
|
Phone Book Capacity
|
100 in Modem
|
vCard version
|
2.1/3.0
|
New contacts
|
Supported
|
Edit contacts
|
Supported
|
Delete contacts
|
Supported
|
Delete contacts
|
Supported
|
Move between Modem, SIM card and PC
|
Supported
|
SMS
|
|
SMS Capability
|
255 in Modem
|
Group messages
|
Supported
|
New SMS
|
Supported
|
Send SMS
|
Supported
|
save SMS to drafts
|
Supported
|
Reply SMS
|
Supported
|
Forward SMS
|
Supported
|
Delete SMS
|
Supported
|
Import from SIM/Modem to PC
|
Supported
|
Attention
|
For MAC OS: 1.Mac Book, Mac Book Pro, iMac, Mac
Pro or Mac mini (Intel CPU) 2.Mac OS X 10.4.9 or higher
3.Support connection to Internet only .
|
Micromax 350G
Specificaion
Model
|
MMX 350G HSDPA USB Modem
|
Technical Standard
|
|
HSDPA
|
3GPP Release5,category 5/6, up to 3.6 Mbps DL and
384 Kbps UL
|
UMTS
|
3GPP Release4, up to 384 Kbps DL and UL
|
EDGE
|
3GPP Release4, multislot class 12, up to 237 Kbps
|
GPRS
|
3GPP Release4, multislot class 10, up to 85.6Kbps
|
Frequency Band
|
|
GSM/GPRS/EDGE
|
900/1800/1900 MHz
|
UMTS
|
2100 MHz
|
Power Class
|
|
WCDMA
|
Power Class 3
|
GSM 850/900
|
Power Class 4
|
EDGE 850/900/1800/1900
|
Power Class E2
|
External Interface
|
|
UMTS/GSM Antenna
|
Supported, Internal Antenna
|
USB Type
|
Fixed Full-Size USB Cable
|
USB Speed
|
USB 2.0 High Speed
|
Power Mode
|
Powered via the USB interface
|
SIM/USIM Card
|
Standard 6 PIN SIM card interface, compaliant with
3GPP 31.101 and 31.102
|
AT Interface
|
3GPP TS 27.005/3GPP TS27.007 supported
|
Main Features
|
|
Form Factor
|
Fish Design With cable
|
Dimension (mm)
|
45.0(L) * 45.0(W) * 9(H)
|
Weight
|
30gm
|
Visual Indicator(LED)
|
RGB LED indicator for different state.
|
NDIS Driver
|
Supported
|
Languages Supported
|
English
|
Zero-CD installation
|
Supported
|
Operate System Supported
|
Windows2000 sp4/ XP sp2/ VISTA sp1/ 7
Mac OS X 10.4.9 or higher (only support INTEL
platform), up to 10.6.0
|
Main Software Functions
|
|
Setup Mode
|
Plug & Auto Installation
|
PIN1
|
Supported,enable/disable/modify
|
SMS
|
Supported
|
PhoneBook
|
Supported
|
APN auto management
|
Supported
|
SMS and Data service simultaneously Operation
|
Supported
|
Phone Book
|
|
vCard version
|
3.0
|
New contacts
|
Supported
|
Edit contacts
|
Supported
|
Delete contacts
|
Supported
|
Sen SMS
|
Supported
|
Move between SIM card and PC
|
Supported
|
SMS
|
|
Group messages
|
Supported
|
New SMS
|
Supported
|
Send SMS
|
Supported
|
save SMS to drafts
|
Supported
|
Reply SMS
|
Supported
|
Forward SMS
|
Supported
|
Delete SMS
|
Supported
|
Import from SIM/Modem to PC
|
Supported
|
Additional Features
|
|
Micro-SD Card Slot
|
Supported, Max up to 16GB
|
Attention
|
For MAC OS:
1.Mac Book, Mac Book Pro, iMac, Mac Pro or Mac mini (Intel CPU) 2.Mac OS X 10.4.9 or higher, up to 10.6.0 |
Specifications are subject to change without prior notice. Services and some
features may be dependent on the network service/content providers, SIM Card,
compatibility of the devices used and the content formats supported. *Talk and
Standby time are affected by network preferences, type of SIM cards, connected
accessories and individual usage patterns.
